YU-USB2-CPI-01-100

$11.50

Description

USB2.0 type A male with 1M cable

The Cnlinko YU-USB2-CPI-01-100 is a USB 2.0 male plug with 1 meter of cable. Male plugs on both ends, with one side overmolded. Rated for 1.5A. 1/2 bayonet connection on overmolded side. Designed to operate under harsh conditions. Creates a reliable connection with easy installation.

Specifications

  • Type- Male Plug / Overmolded Male Plug
  • Cable Length- 1 Meter (3.28 Ft)
  • Number of Contacts- 4
  • Rated Current- 1.5 A
  • Contact Resistance- <30 mOhm
  • Withstanding Voltage- 500V
  • Insulation Resistance- >500 MOhm
  • Ingress Protection- IP 67 (when mated)
  • Durability- > 500 times
  • Operating Temperature- -40 C to 80 C (-40 F to 176 F)
  • Housing Material- High performance engineering plastic
  • Flammability Rating- UL94-V0
  • Approvals- CE, RoHS, ISO 9001

CNLINKO USB 2.0 PLUG WITH 1 METER MOLDED CABLE YU-USB2-CPI-01-100
