Female Socket with 2 positions on a 3.5mm pitch and solder termination, rated 8A at 300V.
Lead times vary by quantity and current production. Please confirm your lead time with Micro-Ray sales before ordering. Contact sales
This part is available made to order. Send us the quantity you need and we will come back with pricing and a firm lead time.
MR-15EDGRC-THR-3.5-02P-13-10A(H) is a Micro-Ray 15EDGRC-THR series euro-style pluggable terminal block (Female Sockets) with 2 positions, a 3.5mm pitch, solder termination.
Cross-references to Phoenix Contact MC 1,5/ 2-G-3,5 THT – 1937499. Phoenix Contact is a trademark of its owner; Micro-Ray is not affiliated with or endorsed by Phoenix Contact.
| Series | 15EDGRC-THR |
|---|---|
| Type | Female Sockets |
| Pitch | 3.5mm |
| Positions | 2 |
| Levels | 1 |
| Positions per Level | 2 |
| Termination | Solder |
| Mounting | Through Hole |
| Wire Entry Angle | O° |
| Current (UL) | 8A |
| Voltage (UL) | 300V |
| Current (IEC) | 8A |
| Voltage (IEC) | 250V |
| Wire Range (AWG) | |
| Wire Range (mm2) | |
| Strip Length | |
| Screw Size | |
| Screw Torque | |
| Operating Temperature | -40℃~130℃ |
| Housing Material | High temperature resistant materials |
| Contact Material | copper |
| Contact Finish | Tin |
| Flammability Rating | UL94V-0 |
| Colour | Black |
| Part Number (SKU) | MR-15EDGRC-THR-3.5-02P-13-10A(H) |
|---|---|
| Category | Female Sockets |
| Series | 15EDGRC-THR |
| Type | Female Sockets |
| Pitch | 3.5mm |
| Positions | 2 |
| Levels | 1 |
| Positions per Level | 2 |
| Termination | Solder |
| Mounting | Through Hole |
| Wire Entry Angle | O° |
| Current (UL) | 8A |
| Voltage (UL) | 300V |
| Current (IEC) | 8A |
| Voltage (IEC) | 250V |
| Operating Temperature | -40℃~130℃ |
| Housing Material | High temperature resistant materials |
| Contact Material | copper |
| Contact Finish | Tin |
| Flammability Rating | UL94V-0 |
| Colour | Black |
| Availability | Made to Order |
| Typical Lead Time | 8-10 weeks |
