MR-AD16-22D-RG - ×22 mm Dual-Colour Pilot Indicator - Red / Green.
Micro-Ray is a value-added distributor. Most products can be customized to your requirement - modified terminations and lengths, custom cable assemblies, control panels and light PC board assembly. Call (732) 892-8799 and tell us what you need.
Send us the quantity you need and we will come back with pricing and a firm lead time.
The MR-AD16-22D-RG is a 22 mm red / green dual-colour LED pilot indicator with shock-proof screw terminals, AC/DC or AC, IP40 or IP65.
Ordering. The ordering code is MR-AD16-22D-RG-X-X-X: each X is replaced by the option you need - voltage (6V = AC/DC 6 V, 12V = AC/DC 12 V, 24V = AC/DC 24 V, 110V = AC/DC 110 V, 220V = AC/DC 220 V, 380V = AC/DC 380 V, AC110V = AC 110 V, AC220V = AC 220 V, AC380V = AC 380 V); voltage dropping (none = Standard, K = Anti-interference, F = Capacitor discharge); protection (none = IP40, P = IP65). The part numbers are listed below.
Still being confirmed. How the red / green colour pair is written in the part number is being confirmed with the factory and not published here yet. Ask us and we will send it with the quotation.
Please call for pricing and availability.
| Part Number (SKU) | MR-AD16-22D-RG |
|---|---|
| Also ordered as | AD16-22D (dual colour) |
| Category | Indicator Lights, Switches |
| Ordering code | MR-AD16-22D-RG-X-X-X |
| Type | Dual-colour pilot indicator, LED |
| Colours | Red and green; other colour pairs to order |
| Wiring | Red X1-X0, green X2-X0 (AC/DC types also yellow X1-X2); AC dual-colour types must not be miswired |
| Series | AD16 pilot indicators |
| Operating environment | −25 °C to +55 °C, altitude below 2000 m |
| Lamp type | LED |
| LED life | 40,000 hours min |
| Voltage fluctuation | ±20 % (110 V and above) |
| Rated impulse withstand voltage | 2.5 kV (AC RMS), 1 min |
| Frequency (AC) | 50 Hz to 60 Hz |
| Rated current | 20 mA max |
| Brightness | 100 cd/m² min |
| Comparative tracking index | CTI 100 min |
| Insulation resistance | 5 MΩ (Ui up to 60 V), 50 MΩ (60 V to 660 V) |
| AC frequency | AC types 50 Hz to 60 Hz only |
| Anti-interference type | Starting voltage 35 V to 45 V; higher starting voltage to order |
| Circuit | Built-in resistor on AC/DC types; capacitor on AC types |
| Connection note | Use a 2.5 × 0.8 mm plug with protective cover where possible; if soldering, iron below 30 W and within 3 s |
| Lens material | High-strength polycarbonate |
| Mounting hole | Ø22 mm (also fits a 25 mm hole) |
| Bezel | Ø29 mm |
| Panel thickness | 6 mm max |
| Head length | 13 mm |
| Body length behind panel | 50 mm |
| Terminals | Screw terminals; anti-electric-shock structure |
| Protection class | IP40 standard, IP65 to order (P) |
| Availability | Please call for pricing and availability |
