Micro-Ray NEMA 5-20R cord-mount power receptacle, 125V AC, wire-lead terminals with cULus recognized contact rating.
Lead times vary by quantity and current production. Please confirm your lead time with Micro-Ray sales before ordering. Contact sales
Micro-Ray is a value-added distributor. Most products can be customized to your requirement - modified terminations and lengths, custom cable assemblies, control panels and light PC board assembly. Call (732) 892-8799 and tell us what you need.
Send us the quantity you need and we will come back with pricing and a firm lead time.
MR-EQT090801
Specifications
| Part Number (SKU) | MR-EQT090801 |
|---|---|
| Category | Industrial Connectors |
| Model | NEMA 5-20R |
| Rated Voltage | 125V AC |
| Rated Current | 20A (12 AWG) / 10A (16-18 AWG) |
| Withstand Voltage | AC 2000V, 1 minute |
| Insulation Resistance | 100MΩ Min |
| Contact Resistance | 30mΩ Max |
| Housing Material | PA66, UL94V-0, black |
| Terminal Material | Phosphor bronze, T=0.7mm |
| Operating Temperature | -10°C to +75°C |
| Storage Temperature | -10°C to +65°C |
| Availability | Please call for lead-time |
| Typical Lead Time | Please call for stock check or lead-time |
