Fork and Spade Terminals

Fork and spade terminals – 178 crimp terminals in vinyl, nylon and PC-insulated, non-insulated and heat-shrink waterproof styles, in flange, locking and plain tongues.

A fork or spade slides in under a screw you only slacken, instead of one you have to take right out. On a crowded terminal block that turns a fiddly job into a quick one, and it is why these shapes survive on control panels long after ring terminals have been designed out of everything else.

What is in this range

• Fork terminals — non-insulated and PC-insulated, butted and brazed seam.
• Spade terminals — narrow, medium and long tongue, single and double crimp with an easy-entry copper sleeve.
• Flange spade terminals — a turned-up flange that stops the wire barrel rotating under the screw.
• Locking spade terminals — a formed tongue that resists backing out under vibration.
• Heat-shrinkable waterproof spades — an adhesive-lined sleeve that seals the crimp.

Specifying one

Four things settle it: the wire size, the stud or screw size the tongue has to clear, the insulation material, and whether the seam is butted or brazed. Wire range, stud size and crimp tooling are confirmed against the manufacturer data sheet on your quotation. Please call for pricing and availability.
