Explore Winmate IM30SB3-101, an industrial embedded computer featuring Android, Linux, ARM A53 Quad Core 2.0GHz CPU for industrial automation and embedded…
Lead times vary by quantity and current production. Please confirm your lead time with Micro-Ray sales before ordering. Contact sales
Micro-Ray is a value-added distributor. Most products can be customized to your requirement - modified terminations and lengths, custom cable assemblies, control panels and light PC board assembly. Call (732) 892-8799 and tell us what you need.
Send us the quantity you need and we will come back with pricing and a firm lead time.
Explore Winmate IM30SB3-101, an industrial embedded computer featuring Android, Linux, ARM A53 Quad Core 2.0GHz CPU for industrial automation and embedded…
The IM30SB3-101 industrial box pc has a compact design of 180 x 110 x 55 mm (one layer, without mounting bracket) made of metal housing to withstand industrial challenges. Its fanless design offers an optimized thermal solution for a reliable and long-lasting industrial technology. Deliver reliable operation in limited space, poor ventilation, dust-prone, and corrosive conditions.
Winmate’s IM30SB3-101 industrial box pc features a secure, seamless edge-to-cloud connection, and scalable computing performance based on an A53 Quad-core processor.
IM30SB3-101 box pc supports superior connectivity enabling seamless interconnection, ensuring interoperability between systems, enabling seamless edge-to-cloud connection, data aggregation, filtering, and data transmission. Easily collect data from a swarm of edge devices through a comprehensive I/O set and transmit it to the cloud over wireless communications.
| System Specification | |
|---|---|
| Processor | ARM A53 (Quad Core 2.0GHz) |
| Memory | 4GB LPDDR4 |
| Storage | eMMC: Onboard 32 GB |
| Operating System | Android 11 (Upgradeable to Android 13) (Default), Linux Yocto 5.10.104 with QT 5.15 (Optional), Linux Ubuntu (Optional) |
| Mechanical | |
| Dimension | 205 x 110 x 55 mm |
| Weight | 1.1 kg |
| Enclosure | Desk Mount |
| Cooling System | Fanless design |
| Environment | |
| Operating Humidity | 10% to 90% RH, Non-Condensing |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -10°C to 60°C |
| Certification | |
| Certification | CE, FCC |
| IO Ports | |
| USB Port | 2 x USB 2.0 Type A , 1 x Micro USB 2.0 OTG |
| Serial Port | 1 x RS232/422/485 |
| LAN | 1 x RJ45, Optional PoE(PD, 802.3AT), |
| Video | 1 x Micro HDMI (Optional) |
| SD Card Slot | 1 x Micro SD card slot (Max to 32GB) |
| SIM Card Slot | 1 x Micro SIM Card Slot |
| Power Input | 1 x 3-Pin Terminal Block, 12V DC |
| Control | |
| Button | 1 x Power Button |
| Accessory | |
| Accessory | 100~240V AC to DC Adapter, Power Cord |
| Power | |
| Power Rating | 12V DC in |
| Ordering | |
| Brand | Winmate |
| Manufacturer part number | IM30SB3-101 |
| Series | M Series Box PC |
| Availability | Please call for pricing and availability |
Micro-Ray Electronics is a Winmate distributor. Winmate offers memory, storage, operating system and wireless options on most models; tell us the configuration you need and we will quote it. Please call (732) 892-8799 or email sales@micro-ray.com for pricing and availability.
Specifications are published by Winmate and are subject to change without notice.
| Part Number (SKU) | IM30SB3-101 |
|---|---|
| Category | Box PC / Waterproof Rugged PC IP65, Embedded Computing, Winmate |
| Processor | ARM A53 (Quad Core 2.0GHz) |
| Memory | 4GB LPDDR4 |
| Storage | eMMC: Onboard 32 GB |
| Operating System | Android 11 (Upgradeable to Android 13) (Default), Linux Yocto 5.10.104 with QT 5.15 (Optional), Linux Ubuntu (Optional) |
| Dimension | 205 x 110 x 55 mm |
| Weight | 1.1 kg |
| Enclosure | Desk Mount |
| Cooling System | Fanless design |
| Operating Humidity | 10% to 90% RH, Non-Condensing |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -10°C to 60°C |
| Certification | CE, FCC |
| USB Port | 2 x USB 2.0 Type A , 1 x Micro USB 2.0 OTG |
| Serial Port | 1 x RS232/422/485 |
| LAN | 1 x RJ45, Optional PoE(PD, 802.3AT), |
| Video | 1 x Micro HDMI (Optional) |
| SD Card Slot | 1 x Micro SD card slot (Max to 32GB) |
| SIM Card Slot | 1 x Micro SIM Card Slot |
| Power Input | 1 x 3-Pin Terminal Block, 12V DC |
| Button | 1 x Power Button |
| Accessory | 100~240V AC to DC Adapter, Power Cord |
| Power Rating | 12V DC in |
| Brand | Winmate |
| Manufacturer part number | IM30SB3-101 |
| Series | M Series Box PC |
| Availability | Please call for lead-time |
| Typical Lead Time | Please call for stock check or lead-time |
