Quick Disconnects

Push-on terminals let a wire come off for service without tools and without undoing a screw. They come as a pair: a female receptacle on the wire and a male tab on the equipment.

Fully-insulated versions shroud the whole body, so nothing live is exposed when the connection is half made — the right choice on anything mains-powered or anywhere fingers can reach.

Piggy back receptacles carry a tab on the back so you can take a second wire off the same terminal without doubling two crimps onto one tab. Bullet connectors are the round push-together pair common in automotive and appliance looms. Flag versions turn the exit through 90° where there is no depth behind the terminal.

Tab sizes are quoted in the part number (110, 187, 205, 250 and so on, in thousandths of an inch). Tell us the tab size and wire size and we will match it.
