Explore Winmate M700DM9, a rugged tablet PC featuring 7-inch display with 1280x720 resolution, IP65 for field service and inspection.
Lead times vary by quantity and current production. Please confirm your lead time with Micro-Ray sales before ordering. Contact sales
Micro-Ray is a value-added distributor. Most products can be customized to your requirement - modified terminations and lengths, custom cable assemblies, control panels and light PC board assembly. Call (732) 892-8799 and tell us what you need.
Send us the quantity you need and we will come back with pricing and a firm lead time.
Explore Winmate M700DM9, a rugged tablet PC featuring 7-inch display with 1280x720 resolution, IP65 for field service and inspection.
The M700DM9 industrial Android tablet works in temperatures from -20 to 60 degrees Celsius while charging. It can operate from -10 to 50 degrees Celsius when using battery power. This versatility makes it ideal for cold chain logistics and various industrial applications.
The 7-inch Android tablet has a sunlight-readable screen. It features a 1280 x 720 TFT LCD display. The optical bonding technology gives great visibility and true colors, even in bright light. This industrial Android tablet works well on the road, in a warehouse, or in a store. It is built for reliable performance in any setting.
The M700DM9 has an 8MP front camera and a 13MP rear camera. It also includes an LED light and autofocus for quick and accurate data capture. Additionally, it offers an optional 1D/2D barcode scanner for enhanced data collection capabilities.
The M700DM9 has US Defense Standard 810G certification. It is lightweight, compact, and rugged. This design makes it suitable for many industrial fields. This tablet can be used in vehicles with its docking station and adapter. It can also be easily changed into a handheld device. Simply store it in a carry bag for complete mobility.
| Display | |
|---|---|
| Size | 7.0 inches |
| Resolution | 1280x720 |
| Type | Projected Capacitive Multi Touch |
| Panel Brightness | 650 nits |
| Contrast Ratio | 800:1 |
| View Angles | 80,80,80,80 |
| Bonding | Optical Bonding for Sunlight Viewability |
| Touch Mode | Support Hand / Gloves and Rain Mode |
| System Specification | |
| Processor | ARM A73 x 4 (2.0 GHz) + A53 x 4 (2.0 GHz) |
| Memory | 4GB |
| Storage | 64GB |
| Operating System | Android 11.0 |
| WLAN | Support |
| BT | Support |
| WWAN | 4G/LTE (Optional) |
| GNSS | GPS/GLONASS |
| RFID | NFC (Read / Write, Peer to Peer mode) (Optional) |
| Sensors | Ambient Light Sensor, E-Compass, Gyro, Acceleration Sensors |
| Camera | |
| Front Camera | 8MP Camera |
| Rear Camera | 13MP Camera with LED Auxiliary Light (Auto Focus) |
| Mechanical | |
| Dimension | 212.4 x 132.8 x 19 mm |
| Weight | 550g |
| IO Ports | |
| USB Port | 1 x USB Type C OTG |
| Audio | 1 x Audio Combo connector (Mic in and Line Out), 2 x Built-in Mic, 1 x Speaker, 1 x Earphone |
| SD Card Slot | 1 x Micro SD Card Slot |
| SIM Card Slot | 1 x Micro SIM Card Slot |
| Indicator | 2 x LED Indicators, (Power, Battery) |
| Docking Connector | 1 x Docking Connector |
| Environment | |
| Operating Humidity | 5% to 95% RH, Non-Condensing |
| Operating Temperature | -10°C to 50°C (Battery mode), -20°C to 60°C (Charging mode) |
| Storage Temperature | -30°C to 70°C |
| Shock | MIL-STD-810H Method 516.8 Procedure I |
| Vibration | MIL-STD-810H Method 514.8 Procedure I |
| Drop | MIL-STD-810H Method 516.8, 5 ft |
| IP rating | IP65 |
| Certification | |
| Certification | CE, FCC |
| Control | |
| Button | 1 x Volume + ,1 x Volume - , 1 x Power Button, 1 x Home Button, 1 x Menu Button, 1 x Return Button, 1 x Trigger Button |
| Power | |
| Battery | 3.7V 5300mAh (Default), Warm swappable function (Optional) |
| Battery Operating Time | 20Hr |
| Power Rating | DC 5V |
| Adapter | Input: 100V-240V AC, Output: DC 5V 3A |
| Security Function | |
| SOTI MobiControl | SOTI MobiControl Compliance |
| Accessory | |
| Accessory | Universal Adapter x1, Battery x1 |
| Optional Accessory | USB Type-C Cable x1, Battery Charging Dock, Vehicle Dock (Charging + Connectors), Vehicle Dock (Charging Only), Desk Dock, Hand Strap, Micro SD Card, Capacitive Touch Stylus, Vehicle Adapter, USB-C to HDMI Adapter |
| Barcode Scanner | |
| Barcode Scanner | 1D/2D Barcode Reader (Optional) |
| Ordering | |
| Brand | Winmate |
| Manufacturer part number | M700DM9 |
| Series | M700 Series Rugged Tablet |
| Availability | Please call for pricing and availability |
Micro-Ray Electronics is a Winmate distributor. Winmate offers memory, storage, operating system and wireless options on most models; tell us the configuration you need and we will quote it. Please call (732) 892-8799 or email sales@micro-ray.com for pricing and availability.
Specifications are published by Winmate and are subject to change without notice.
| Part Number (SKU) | M700DM9 |
|---|---|
| Category | Android Rugged Tablets, Enterprise Mobility, Winmate |
| Size | 7.0 inches |
| Resolution | 1280x720 |
| Type | Projected Capacitive Multi Touch |
| Panel Brightness | 650 nits |
| Contrast Ratio | 800:1 |
| View Angles | 80,80,80,80 |
| Bonding | Optical Bonding for Sunlight Viewability |
| Touch Mode | Support Hand / Gloves and Rain Mode |
| Processor | ARM A73 x 4 (2.0 GHz) + A53 x 4 (2.0 GHz) |
| Memory | 4GB |
| Storage | 64GB |
| Operating System | Android 11.0 |
| WLAN | Support |
| BT | Support |
| WWAN | 4G/LTE (Optional) |
| GNSS | GPS/GLONASS |
| RFID | NFC (Read / Write, Peer to Peer mode) (Optional) |
| Sensors | Ambient Light Sensor, E-Compass, Gyro, Acceleration Sensors |
| Front Camera | 8MP Camera |
| Rear Camera | 13MP Camera with LED Auxiliary Light (Auto Focus) |
| Dimension | 212.4 x 132.8 x 19 mm |
| Weight | 550g |
| USB Port | 1 x USB Type C OTG |
| Audio | 1 x Audio Combo connector (Mic in and Line Out), 2 x Built-in Mic, 1 x Speaker, 1 x Earphone |
| SD Card Slot | 1 x Micro SD Card Slot |
| SIM Card Slot | 1 x Micro SIM Card Slot |
| Indicator | 2 x LED Indicators, (Power, Battery) |
| Docking Connector | 1 x Docking Connector |
| Operating Humidity | 5% to 95% RH, Non-Condensing |
| Operating Temperature | -10°C to 50°C (Battery mode), -20°C to 60°C (Charging mode) |
| Storage Temperature | -30°C to 70°C |
| Shock | MIL-STD-810H Method 516.8 Procedure I |
| Vibration | MIL-STD-810H Method 514.8 Procedure I |
| Drop | MIL-STD-810H Method 516.8, 5 ft |
| IP rating | IP65 |
| Certification | CE, FCC |
| Button | 1 x Volume + ,1 x Volume - , 1 x Power Button, 1 x Home Button, 1 x Menu Button, 1 x Return Button, 1 x Trigger Button |
| Battery | 3.7V 5300mAh (Default), Warm swappable function (Optional) |
| Battery Operating Time | 20Hr |
| Power Rating | DC 5V |
| Adapter | Input: 100V-240V AC, Output: DC 5V 3A |
| SOTI MobiControl | SOTI MobiControl Compliance |
| Accessory | Universal Adapter x1, Battery x1 |
| Barcode Scanner | 1D/2D Barcode Reader (Optional) |
| Brand | Winmate |
| Manufacturer part number | M700DM9 |
| Series | M700 Series Rugged Tablet |
| Availability | Please call for lead-time |
| Typical Lead Time | Please call for stock check or lead-time |
