Explore Winmate RG100-SUIT, an industrial computer solution featuring Wireless Connection(4G/ WLAN) Radio Gateway, Support DMR…
Utilizing the WinVoIP server and the RG100-SUIT RoIP Gateway, event organizers can communicate with their teams swiftly and efficiently. Whether through radios or smartphone apps, team members can quickly respond to any situation with ease.
Winmate addresses interoperability challenges with the RG100-SUIT, offering voice and radio connectivity in a compact form. By directly connecting up to two donor radios to the RG100-SUIT, users can effortlessly link different radio networks, endpoints, or frequencies, ensuring smooth communication between organizations.
When radio signals are weak at the rescue site, the RG100-SUIT can be used on ambulances or fire engines to transmit signals through the Win Radio Cloud Server. This setup ensures communication between staff and command centers using radios and smartphones (via apps), even from remote offices.
With a 108.5Wh battery, this device can run for 9 hours without interruption. The efficient battery design supports extended usage, allowing for continuous operation during long shifts. Maintain productivity with reliable, all-day power.
| Router Management | |
|---|---|
| Router Management | Web Based Configuration , HTTPS, Web Software Upgrade , Configuration Backup and Restore , Reset to Default Button , |
| IP Network Spec | |
| Network Security Specifications | HTTPS, |
| WAN | Static IP, DHCP |
| Network Protocol Support | SIP Client, NTP Client, DNS Client, Web Server,DHCP Server, SSH Server |
| IPv4 | Support |
| IO Ports | |
| USB Port | 2 x USB 3.0 |
| SD Card Slot | 1 x Micro SD Card Slot |
| SIM Card Slot | 1 x SIM card slot |
| Indicator | Radio, WAN, LAN, Register, Alarm, Power |
| DIDO | DIDO (4XDI ; 4XDO) |
| RJ-45 | 1 x WAN, 1 x LAN, 2 x Radio (Optional for 4 radio ports/6 radio ports) |
| Certification | |
| Certification | CE, FCC |
| System Specification | |
| Memory | 4GB RAM |
| Storage | 64GB SSD |
| Operating System | Ubuntu |
| RF Spec | |
| Frequency Range | VHF：134~174MHz or UHF：400~470 MHz |
| LTE Band | B1/B3/B5/B7/B8/B20/B28/B32 |
| WLAN | Support |
| Mechanical | |
| Dimension | 274 x 227 x 155 mm |
| Weight | 4.5Kg |
| Enclosure | Plastic |
| Transmitter Spec | |
| TX Power | 4W |
| RX Sensibility | ≤-121dBm |
| Channel Spacing | Analog: 12.5KHz / 25kHz , Digital: 12.5KHz |
| Environment | |
| Operating Temperature | 0~60°C |
| Vibration | MIL-STD-810G Method 514.6 |
| Control | |
| Button | 1 x Power Switch (On/ Off), 2 x Button (Change Channels) |
| Power | |
| Power Rating | 9~36V DC input(Terminal Block), AC in |
| Ordering | |
| Brand | Winmate |
| Manufacturer part number | RG100-SUIT |
| Series | Radio Gateway |
| Availability | Please call for pricing and availability |
Micro-Ray Electronics is a Winmate distributor. Winmate offers memory, storage, operating system and wireless options on most models; tell us the configuration you need and we will quote it. Please call (732) 892-8799 or email sales@micro-ray.com for pricing and availability.
Specifications are published by Winmate and are subject to change without notice.
| Part Number (SKU) | RG100-SUIT |
|---|---|
| Category | Embedded Computing, IoT Gateway / Radio Gateway, Winmate |
| Router Management | Web Based Configuration , HTTPS, Web Software Upgrade , Configuration Backup and Restore , Reset to Default Button , |
| Network Security Specifications | HTTPS, |
| WAN | Static IP, DHCP |
| Network Protocol Support | SIP Client, NTP Client, DNS Client, Web Server,DHCP Server, SSH Server |
| USB Port | 2 x USB 3.0 |
| SD Card Slot | 1 x Micro SD Card Slot |
| SIM Card Slot | 1 x SIM card slot |
| Indicator | Radio, WAN, LAN, Register, Alarm, Power |
| DIDO | DIDO (4XDI ; 4XDO) |
| Certification | CE, FCC |
| Memory | 4GB RAM |
| Storage | 64GB SSD |
| Operating System | Ubuntu |
| Frequency Range | VHF: 134~174MHz or UHF: 400~470 MHz |
| LTE Band | B1/B3/B5/B7/B8/B20/B28/B32 |
| WLAN | Support |
| Dimension | 274 x 227 x 155 mm |
| Weight | 4.5Kg |
| Enclosure | Plastic |
| TX Power | 4W |
| RX Sensibility | ≤-121dBm |
| Channel Spacing | Analog: 12.5KHz / 25kHz , Digital: 12.5KHz |
| Operating Temperature | 0~60°C |
| Vibration | MIL-STD-810G Method 514.6 |
| Button | 1 x Power Switch (On/ Off), 2 x Button (Change Channels) |
| Power Rating | 9~36V DC input(Terminal Block), AC in |
| Brand | Winmate |
| Manufacturer part number | RG100-SUIT |
| Series | Radio Gateway |
| Availability | Please call for lead-time |
| Typical Lead Time | Please call for stock check or lead-time |
